Analog to Digital, audio, AV Signal Converter
1.0 Introduction
This Analog to Digital Audio Converter is designed for either home
or professional audio switching. It converts analog stereo audio
signal from R/L input to Coaxial and Toslink outputs
simultaneously. The output digital audio signal is 2-channel
uncompressed LPCM (Linear Pulse Code Modulation) with sampling rate
at 48 KHz. This Converter is small in size and quite easy to
install.
2.0 Specifications
| Signal Inputs/Output | |
| Input Audio | Coaxial or Toslink digital audio |
| Output Audio | R/L audio |
| Connector | |
| Input audio connector | Toslink,1XRCA(Coaxial) |
| Output audio connector | 2XRCA(R/L) |
| Sampling rate | 32, 44.1, 48 and 96 KHz |
| Mechanical | |
| Size(LxWxH) | 51x41x26mm |
| Weight (Net) | 78g |
| Warranty | |
| Limited Warranty | 1 Year Parts and Labor |
| Environmental | |
| Operating Temperature | 0 ℃ to +70℃ |
| Operating Humidity | 10% to 85% RH (no condensation) |
| Storage Temperature | -10℃ to +80℃ |
| Storage Humidity | 5% to 90% RH (no condensation) |
| Power Requirement | |
| External Power Supply | DC 5V 1A |
| Power Consumption | 0.5 watts (max) |
| Regulatory Approvals | |
| Converter Unit | FCC,CE,UL |
| Power Supply | UL,CE,FCC |
| Accessories Adapter | |
| AC Power Adapter | US standard, UK standard and so on |
| User Manual | English Version |
Note: Specifications are subject to change without notice.
3.0 Features
This Converter has many features that enable it to perform in a
superior manner. Among those features you will find:
1. Supports uncompressed 2-channel LPCM digital audio signal
output.
2. Supports output sampling rate at 48KHz.
3. Provides electromagnetic-noise-free transmission.
4. Easy to install and simple to operate.
4.0 Package Contents
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
1. Analog to Digital Audio Converter-------------------1 PCS
2. < >V DC Power Supply-----------------------------------1
PCS < >’s Manual--------------------------------------------1 PCS
5.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the
signal input(s), output(s) and power requirements.
1. Toslink: Toslink Digital Audio Output port
2. Coaxial: Coaxial Digital Audio Output port
3. Power: Power Input Status Indicator
4. DC 5V: 5V Power Input port
5. R/L: R/L Audio Input port
6.0 Connection and Operation
Before installation, please make sure all devices you wish to
connect have been turned off.
1. Connect the audio source device to the Converter using appropriate
R/L cable.
2. Connect the A/V Receivers or Amplifiers to the Converter using
appropriate Toslink or Coaxial cables.
3. Insert the DC side of 5v power supply into the converter and
then connect the AC side of the power supply into the wall outlet.
Attention: Insert / Extract cable gently.
